FEATURES
Wattage Selectable
Multi-wattage options in a single fixture for flexible applications and reduced inventory.
CCTS Tunable
Adjustable colortemperature to suit diverse environments.
High Efficacy & Energy Saving
Up to 130 lm/W or 140 lm/W, reducing energy consumption by over 60% compared with HID fixtures.
Smart control Ready
Compatible with 0-10V / DALI dimming, optional microwave/infrared sensor, and emergency kit.
Reliable Warranty
5 Years Warranty.
TECHNICAL PARAMETERS
Product Model | TF22-40W | TF24-50W |
|---|---|---|
Wattage Selectable | 40W/35W/30W/25W/20W | 50W/40W/30W/25W/20W |
Input Voltage | AC120-277V | AC120-277V |
Luminous Efficacy | 130lm/W 140lm/W | 130lm/W 140lm/W |
Wattage Selectable | 5200lm/4550lm/3900lm/3250lm/2600lm 5600lm/4900lm/4200lm/3500lm/2800lm | 6500lm/5200lm/3900lm/3250lm/2600lm 7000lm/5600lm/4200lm/3500lm/2800lm |
CCT Selectable | 3500K/4000K/5000K/5700K/6500K | 3500K/4000K/5000K/5700K/6500K |
CRI | Ra>80 | Ra>80 |
Beam Angle | 120° | 120° |
Ingress Protection | IP20 | IP20 |
Impact Resistance | IK04 | IK04 |
Net Weight | 2.7kg | 4.9kg |
Dimensions | 603x603x52.83mm | 1213x603x52.83mm |
IES



Accessories

Motion Sensor
