LED HIGH BAY

LED HIGH BAY

The FGE-HBUP Series High Bay is engineered for demanding industrial and commercial high-ceiling applications. Equipped with high-efficacy LED chips and precision optical lenses, it delivers up to 150 lm/W, providing uniform and glare-free illumination while significantly reducing energy consumption.

The FGE-HBUP Series High Bay is engineered for demanding industrial and commercial high-ceiling applications. Equipped with high-efficacy LED chips and precision optical lenses, it delivers up to 150 lm/W, providing uniform and glare-free illumination while significantly reducing energy consumption.

Gallery image 1
Thumbnail 1
Thumbnail 2
Gallery image 1
Thumbnail 1
Thumbnail 2
Gallery image 1
Thumbnail 1
Thumbnail 2

FEATURES

Wattage Selectable

Multi-wattage options in a single fixture for flexible applications and reduced inventory.

CCTS Tunable

Adjustable colortemperature to suit diverse environments.

High Efficacy & Energy Saving

Up to 150 lm/W, reducing energy consumption by over 60% compared with HID fixtures.

Smart control Ready

Compatible with 0-10V / DALI dimming, optional microwave/infrared sensor, and emergency kit.

Reliable Warranty

5 / 7 / 10 Years Warranty Options.

HBUP UFO high bay light IP65 waterproof dustproof IK08 impact resistant industrial lamp

Robust Protection

IP65 waterproof & dustproof, IK08 impact resistance for harsh industrial environments.

HBUP UFO LED high bay ADC12 die cast aluminum heat sink thermal dissipation design

Superior Thermal Management

ADC12 die-cast aluminum housing with optimized heat sink for reliable performance.

HBUP UFO high bay light IP65 waterproof dustproof IK08 impact resistant industrial lamp

Robust Protection

IP65 waterproof & dustproof, IK08 impact resistance for harsh industrial environments.

HBUP UFO LED high bay ADC12 die cast aluminum heat sink thermal dissipation design

Superior Thermal Management

ADC12 die-cast aluminum housing with optimized heat sink for reliable performance.

HBUP UFO high bay light IP65 waterproof dustproof IK08 impact resistant industrial lamp

Robust Protection

IP65 waterproof & dustproof, IK08 impact resistance for harsh industrial environments.

HBUP UFO LED high bay ADC12 die cast aluminum heat sink thermal dissipation design

Superior Thermal Management

ADC12 die-cast aluminum housing with optimized heat sink for reliable performance.

TECHNICAL PARAMETERS

Product Model

HBUP-500W

Wattage Selectable

500W/400W/300W

Input Voltage

AC120–277V/277–480V

Luminous Efficacy

150lm/W

Wattage Selectable

75000lm/60000lm/45000lm

CCT Selectable

4000K/5000K

CRI

Ra>80

Beam Angle

30°/60°/90°

Ingress Protection

IP65

Impact Resistance

IK08

Net Weight

6.55kg

Dimensions

Ø450x269mm

IES

FGE-HBUP300W50K-30deg.ies

FGE-HBUP500W50K-30deg.ies

FGE-HBUP500W50K-60deg.ies

FGE-HBUP500W50K-90deg.ies

HBUP UFO high bay light beam angle options symmetrical 90° 60° 30° light distribution curve

Accessories

Ceiling mounting bracket for HBUP UFO high bay light

Ceiling Bracket

3/4 NPT mounting bracket for HBUP LED high bay

Three Fourths NPT Bracket

Microwave motion sensor accessory for HBUP high bay lamp

Microwave Motion Sensor

PIR human motion sensor for HBUP UFO high bay light

PIR Sensor

Remote controller for HBUP HD07VR-MH HD07VR-PH high bay light

Remote Controller for HD07VR-MH/HD07VR-PH
