DSL

DSL

ALL IN ONE SOLAR LIGHT

ALL IN ONE SOLAR LIGHT

The PKS-DSL All-in-One Solar Light integrates high-efficiency solar panels, a durable battery, high-output LED array, and an intelligent sensor controller into a sleek, compact design. It delivers reliable, self-sustaining illumination for streets, sidewalks, community spaces, and commercial lots—no grid power or external wiring required.

The PKS-DSL All-in-One Solar Light integrates high-efficiency solar panels, a durable battery, high-output LED array, and an intelligent sensor controller into a sleek, compact design. It delivers reliable, self-sustaining illumination for streets, sidewalks, community spaces, and commercial lots—no grid power or external wiring required.

Gallery image 1
Thumbnail 1
Thumbnail 2
Gallery image 1
Thumbnail 1
Thumbnail 2
Gallery image 1
Thumbnail 1
Thumbnail 2

FEATURES

High Efficacy & Energy Saving

Up to 170 lm/W, reducing energy consumption by over 60% compared with HID fixtures.

Smart control Ready

Compatible with 0-10V / DALI dimming, optional microwave/infrared sensor, and emergency kit.

Charge Time

Fully charges in 6 hours for dependable emergency readiness.

Discharge Time

Provides up to 24-36h (2-3 nights) of continuous illumination during power failure.

Reliable Warranty

5 Years Warranty.

All in one solar street light PIR motion sensor demonstration banner, two solar lamps with dim and full brightness triggered by pedestrian at night, smart sensing energy saving feature

PIR Sensor Options

Smart motion sensing for energy saving and extended lifespan.

12V/24V MPPT Controller

Intelligent to control the dimming by PIR/Motion sensor and timer.

12V/24V SRNE MPPT solar charge controller matched with PIR motion sensor, intelligent timing dimming driver for integrated solar street lamp
Black all-in-one solar street light working under thunderstorm, 10KV surge protection, IP65 waterproof, IK08 impact resistance harsh environment banner

10KV Surge & IP65 Heavy-Duty Protection

It features 10KV surge protection, IP65 waterproof & dustproof and IK08 impact resistance for reliable and safe use in harsh industrial environments.

High Brightness

High-brightness LED modules provide sufficient, uniform wide-area illumination at low power consumption, superior to conventional lighting.

High brightness LED module of all-in-one solar street light, uniform wide-area low-power illumination for roadway lighting

High Efficiency Solar Cells

Solar-powered, no external power supply required, energy-saving and eco-friendly.

High efficiency monocrystalline solar cell panel, off-grid solar power module for all-in-one street light, energy saving eco-friendly

Adjustable Sleeve

The sleeve is angle-adjustable for diverse installation needs to optimize road lighting.

Angle adjustable mounting sleeve structure of integrated solar street light, flexible installation to optimize road lighting distribution

Higher Efficiency

High efficiency of conversion by using the new

manufacturing technique and A-class cell.

Circular cycle icon representing high conversion efficiency A-grade solar cells for all-in-one solar street lighting
All in one solar street light PIR motion sensor demonstration banner, two solar lamps with dim and full brightness triggered by pedestrian at night, smart sensing energy saving feature

PIR Sensor Options

Smart motion sensing for energy saving and extended lifespan.

12V/24V MPPT Controller

Intelligent to control the dimming by PIR/Motion sensor and timer.

12V/24V SRNE MPPT solar charge controller matched with PIR motion sensor, intelligent timing dimming driver for integrated solar street lamp
Black all-in-one solar street light working under thunderstorm, 10KV surge protection, IP65 waterproof, IK08 impact resistance harsh environment banner

10KV Surge & IP65 Heavy-Duty Protection

It features 10KV surge protection, IP65 waterproof & dustproof and IK08 impact resistance for reliable and safe use in harsh industrial environments.

High Brightness

High-brightness LED modules provide sufficient, uniform wide-area illumination at low power consumption, superior to conventional lighting.

High brightness LED module of all-in-one solar street light, uniform wide-area low-power illumination for roadway lighting

High Efficiency Solar Cells

Solar-powered, no external power supply required, energy-saving and eco-friendly.

High efficiency monocrystalline solar cell panel, off-grid solar power module for all-in-one street light, energy saving eco-friendly

Adjustable Sleeve

The sleeve is angle-adjustable for diverse installation needs to optimize road lighting.

Angle adjustable mounting sleeve structure of integrated solar street light, flexible installation to optimize road lighting distribution

Higher Efficiency

High efficiency of conversion by using the new

manufacturing technique and A-class cell.

Circular cycle icon representing high conversion efficiency A-grade solar cells for all-in-one solar street lighting
All in one solar street light PIR motion sensor demonstration banner, two solar lamps with dim and full brightness triggered by pedestrian at night, smart sensing energy saving feature

PIR Sensor Options

Smart motion sensing for energy saving and extended lifespan.

12V/24V MPPT Controller

Intelligent to control the dimming by PIR/Motion sensor and timer.

12V/24V SRNE MPPT solar charge controller matched with PIR motion sensor, intelligent timing dimming driver for integrated solar street lamp
Black all-in-one solar street light working under thunderstorm, 10KV surge protection, IP65 waterproof, IK08 impact resistance harsh environment banner

10KV Surge & IP65 Heavy-Duty Protection

It features 10KV surge protection, IP65 waterproof & dustproof and IK08 impact resistance for reliable and safe use in harsh industrial environments.

High Brightness

High-brightness LED modules provide sufficient, uniform wide-area illumination at low power consumption, superior to conventional lighting.

High brightness LED module of all-in-one solar street light, uniform wide-area low-power illumination for roadway lighting

High Efficiency Solar Cells

Solar-powered, no external power supply required, energy-saving and eco-friendly.

High efficiency monocrystalline solar cell panel, off-grid solar power module for all-in-one street light, energy saving eco-friendly

Adjustable Sleeve

The sleeve is angle-adjustable for diverse installation needs to optimize road lighting.

Angle adjustable mounting sleeve structure of integrated solar street light, flexible installation to optimize road lighting distribution

Higher Efficiency

High efficiency of conversion by using the new

manufacturing technique and A-class cell.

Circular cycle icon representing high conversion efficiency A-grade solar cells for all-in-one solar street lighting

TECHNICAL PARAMETERS

Product Model

AthenaIII-60W

AthenaIII-80W

AthenaIII-100W

Wattage

60W

80W

100W

Input Voltage

12V

12V

12V

Luminous Efficacy

170lm/W

170lm/W

170lm/W

Luminous Flux

10200lm

13600lm

17000lm

CCT

3000-6000K Options

3000-6000K Options

3000-6000K Options

CRI

Ra>70

Ra>70

Ra>70

Beam Angle

114°

114°

114°

Ingress Protection

IP65

IP65

IP65

Impact Resistance

IK08

IK08

IK08

Net Weight

11.42kg

14.45kg

17.13kg

Dimensions

1080x445x125mm

1390x445x125mm

1680x445x125mm

IES

LED light intensity distribution polar diagram in C planes, photometric curve of all-in-one solar street light, average beam angle 113.4 degrees
